This lateral seismic brace secures suspended piping against lateral seismic loads using a one-inch by seven-foot schedule forty black steel pipe strut connected at an angle between forty-five and fifty-nine degrees. The upper end attaches to the overhead structural support using a Universal E.Q.B. swivel or approved equal Fig. 980 fitting. The lower end clamps onto the braced utility pipe using a Fig. 1000 fast clamp or approved equal. The assembly accommodates a pipe size designated as S, with sizing notation reflecting a four-inch pipe application.
UNIVERSAL E.Q.B. SWIVEL OR APPROVED EQUAL FIG. 980 1" x 7'-0" SCH. 40 BLACK STEEL PIPE FIG. 1000 FAST CLAMP OR APPROVED EQUAL S = STEEL SIZE OF PIPE BEING BRACED (4") 1x7-0 SB2-S 45-59° HANGER SWAY BRACE CONNECTION LATERAL SEISMIC BRACE
