A condensate drain pipe routed within the wall stubs out to connect to the sink tailpiece. An indirect connection utilizes a branch fitting on the tailpiece, with a hose sloped toward the drain to ensure proper flow. The sink assembly incorporates a standard P-trap below the tailpiece to maintain a water seal.
