This piping schematic outlines a multi-torch gas supply layout featuring six individual tiki torches connected to a main gas line. The system utilizes one-half-inch gas lines running to each torch, branching into three-quarter-inch and one-inch main supply segments. A pressure reducer is specified to maintain two pounds to four ounces of pressure, with a thirty-foot maximum run allowed after the pressure regulator. A designated connection area links the supply to the main gas line.
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
Start membership
