A twenty millimeter domestic hot water supply line and a fifteen millimeter domestic cold water supply line feed into a thermostatic mixing valve set at thirty-five degrees Celsius. Water hammer arrestors and supply stops are installed on the branch lines. The assembly connects to a ten millimeter tempered water main serving multiple lavatory and hand sinks. The unit is installed exposed on the wall behind the sink apron.
20 DHW THERMOSTATIC MIXING VALVE, SET AT 35 DEG C LAVATORY/HAND SINK (TYPICAL) 10 TEMPERED WATER 15 DHW 15 DCW SUPPLY STOP (TYP) TO THIRD LAV WHA-A WHA-A INSTALL EXPOSED ON WALL BEHIND APRON (TYPICAL) RE: E1/I-202
