An existing W16 wide flange steel beam supports a drop-down framing assembly at elevation 32'-0" composed of an existing HSS 3x3x3/16 structural steel tube. Existing HSS 4x3x3/16 members serve as typical headers running perpendicular to support the Kalwall roof panels. Existing P5501 Unistrut channels are spaced at 4'-0" on center and aligned directly with the Kalwall roof panels.
(E) W16 BEAM 7<3$7 DEEP ROOF FRANING ELEV 32'-0" (E) HSS4x3x3/16 LSV TYP HEADER FOR ADDITIONAL INFORMATION SEE - 6 (E) HSS3x3x3/16 (E) P5501 UNISTRUT @ 4'-0" ALIGNED w KALWELL ROOF PANEL
