This concrete slab-on-grade control joint assembly features a saw-cut groove measuring one-eighth inch wide by a depth equal to one-fourth of the slab thickness, filled with a specified rigid material. The concrete slab rests on a compacted sub-grade with thickness and reinforcing sized per plan. Top of slab elevation is established per plan.
SAW CUT 1/8" WIDE X t/4. FILL WITH SPECIFIED RIGID MATERIAL SLAB ON GRADE THICKNESS AND REINFORCING PER PLAN COMPACTED SUB-GRADE T.O. SLAB EL.: PER PLAN t
