An electronic trap primer system is housed within a 12-inch by 12-inch by 4-inch NEMA-1 galvanized steel cabinet. Power is supplied via a 120-volt electrical conduit connection feeding an internal 24-hour timer equipped with a manual override and a 5-amp fuse. A 3/4-inch water source connection feeds the assembly, passing through an atmospheric vacuum breaker and control valve. Four tube connections route water to floor traps and overflow drains, including provisions for future connections and a 1/2-inch domestic cold water line to a hub drain.
24 HR TIMER ATMOSPHERIC VACUUM BREAKER TUBE CONNECTIONS FOR ROUTING TO TRAPS (4-TYP) FUTURE CONNECTION 1/2"DCW TO HUB DRAIN, FLOOR DRAIN AND OVERFLOW DRAIN 3/4" WATER SOURCE CONNECTION 12"X12"X4" NEMA-1 GALVANIZED STEEL CABINET 5 AMP FUSE MANUAL OVERRIDE ELECTRICAL CONDUIT 120V CONNECTION
