A rainwater leader routes water down an interior wall behind furring to a horizontal steel pipe sleeve that penetrates the exterior wall assembly. A downspout nozzle is bolted directly to the exterior wall face and sealed with one-inch-wide caulk around the penetration. The discharged water empties onto a splash block provided by others positioned twelve inches below the nozzle outlet.
NOZZLE EXTERIOR WALL DOWN SPOUT NOZZLE BOLTED TO WALL 1" WIDE CAULK SPLASH BLOCK (BY OTHERS) RAINWATER LEADER FURRING BY OTHERS STEEL PIPE SLEEVE 12"
