A cold water cold water supply main branches into multiple feed lines sized at two inches, four inches, and six inches. One branch connects to the water level control for pool supply, while another serves the spa supply connected to the water level control. A six-inch branch line extends upward to connect to mechanical and pool boiler systems. Pipe sizing indicators specify one and one-quarter inch and six-inch connections at branch risers.
