A water hammer arrestor and quick-closure valve connect to a long run of plumbing piping to absorb hydraulic shock. The arrestor is sized according to Plumbing and Drainage Institute ratings and installed per manufacturer instructions. Location and sizing are determined per the plumbing plans.
1. SEE PLANS FOR SIZE; WATER HAMMER AND DRAINAGE INSTITUTE (PDI) RATING. 2. INSTALL ACCORDING TO MANUFACTURER'S ARRESTOR SIZED ACCORDING TO PLUMBING INSTRUCTIONS. OUTLET SHOCK WATER HAMMER ARRESTOR; SEE PLANS FOR SIZE AND LONG RUN OF PIPING NOTES: LOCATION. QUICK VALVE CLOSURE
