An expansion nut is set into the concrete floor slab to anchor a vertical threaded hanger rod. A standard clevis assembly secures the suspended pipe using double nuts at the top connection. Insulation surrounds the water pipe, with the top of the insulation notched to fit around the hanger hardware. This installation applies to domestic hot water, domestic hot recirculation, and building heating water pipes six inches and smaller in diameter, with gas pipes installed similarly without insulation.
AND SMALLER. AT TOP TO FIT AROUND HANGER TO PIPE SIZES 6" NOTCH INSULATION THIS DETAIL APPLIES NOTE: INSULATION WATER PIPE STANDARD CLEVIS ASSEMBLY HANGER ROD DOUBLE NUT 1. THIS APPLIES TO DOMESTIC HOT, DOMESTIC HOT RECIRCULATION & BLDG HEATING WATER ONLY. 2. GAS PIPE SIMILAR W/O INSULATION EXPANSION NUT INTO CONCRETE FLOOR CONCRETE FLOOR D
