Plumbing · P-AMYAH

Mounting Plate Detail

Units: imperial
Sheet: P1000
Discipline: Plumbing

Materials

Metal (misc.)Steel

Elements

Connections / Plates Partitions

Text on the drawing

0'-4 3/4" 0'-2" 0'-6" BACKING TYPE B PER (6)-#14 SMS TYP MOUNTING PLATE DETAIL A

Members view this detail in full resolution, download the CAD files (SVG, PDF), and open any detail in the built-in CAD editor to edit and export DXF or DWG.
