An inline circulator pump connects to a primary loop piping system with typical ball valves installed on either side for isolation. A triple duty valve combining gate, check, and balancing functions is positioned on the discharge side of the pump. Pressure gauges are located upstream and downstream of the pump to monitor system pressure differentials across the assembly.
3D INLINE PUMP BALL VALVE (TYPICAL) PRIMARY LOOP TRIPLE DUTY VALVE (TYP.) GATE, CHECK, BALANCING. TO SYSTEM PRESSURE GAUGE (TYP)
