A finished floor cleanout tee connects to a vertical riser that may extend as a waste or vent pipe. The cleanout plug is accessed through a stainless steel access cover secured with a vandal-proof countersunk screw. The vertical pipe extends downward through the floor slab to a forty-five degree wye fitting with a plug at the end of the line.
FINISHED FLOOR CLEANOUT TEE MAY EXTEND AS WASTE OR VENT CLEANOUT PLUG STAINLESS STEEL ACCESS COVER WITH VANDAL PROOF COUNTERSUNK SCREW RISER (LENGTH AS REQUIRED) PLUG IF END OF LINE (TYP) 45° WYE FITTING (TYP) FLOW
