A twenty-four-inch diameter by ninety-six-inch deep fiberglass basin is set into the floor and covered with a twenty-eight-inch outside diameter grated steel cover. The submersible pump inside connects to vertical discharge piping equipped with a union, check valve, and shutoff valve leading to a two-inch discharge line with an indirect connection at a floor sink. Tethered float switches provide level control and high water alarm functions connected to a simplex control panel in a NEMA 1 enclosure with a 115-volt single-phase power supply.
24" ∅ BASIN FIBERGLASS BASIN 24" ∅ , 96" DEEP DISCHARGE PIPING & CHECK VALVE HWA FLOOR 28" O.D. GRATED STEEL COVER SHUTOFF VALVE 2" DISCHARGE TO INDIRECT CONNECTION AT FLOOR SINK UNION CHECK VALVE (IF NOT PROVIDED WITH PUMP) TETHERED FLOAT SWITCHES OFF/STOP 115/1 ∅ POWER SUPPLY SIMPLEX CONTROL PANEL IN NEMA 1 ENCLOSURE CONTAINING: -CONTROL POWER ON-OFF SWITCH -MOTOR CONTACTOR -H-O-A SELECTOR SWITCH -PUMP RUNNING LIGHT -HIGH WATER ALARM LIGHT -HIGH WATER ALARM BUZZER WITH SILENCE SWITCH -ISOLATED ALARM CONTACT FOR REMOTE MONITORING -U/L LISTED LABEL -TERMINAL STRIP SP-1
