An electronic trap primer assembly connects to a cold water supply tapped from the top, running through a ball valve and a PPP MP-500 electronic trap primer housed within a metal cabinet. The cabinet is recessed within framed walls or surface mounted on concrete or block walls, with an adjacent 115V controller positioned a minimum of 12 inches above the finished floor. Piping drops down to a PPP one-inch air gap funnel and transitions to one-half-inch Type L soft copper with no joints for below grade runs. All copper piping installed in concrete slabs is wrapped with corrosion protection tape. The horizontal line extends with a maximum twenty-foot run, sloping toward the p-trap connection at the floor drain or sink.
115V CONTROLLER MIN 12" AFF 1/2" TYPE L SOFT COPPER WITH NO JOINTS FOR BELOW GRADE (TYP) - COPPER PIPING IN CONCRETE SLAB SHALL BE WRAPPED WITH CORROSION PROTECTION TAPE METAL CABINET LOCATED IN THE ROOM THE FLOOR DRAIN/FLOOR SINK IS SERVING 1/2" FINISHED FLOOR BALL VALVE PPP MP-500 ELECTRONIC TRAP PRIMER FLOOR DRAIN/ SINK CABINET SHALL BE RECESSED WITHIN FRAMED WALLS AND SURFACE MOUNTED ON CONCRETE/BLOCK WALLS TAP FROM TOP OF SUPPLY E CW SLOPE ALL HORIZONTAL LINES P-TRAP WITH PRIMER CONNECTION PPP 1" AIR GAP FUNNEL NOTE: INSTALLATION SHALL BE IN STRICT ACCORDANCE WITH THE MANUFACTURER'S PRINTED INSTRUCTIONS. UNION 1/2" TUBE x NPT FITTING (TYP) 20' MAX
