An island sink fixture sits within a countertop and cabinet assembly supported by the floor. A one-and-a-half-inch drain pipe extends downward through a long-turn quarter bend and transitions to a two-inch horizontal waste line beneath the floor slab. A vent pipe rises from the waste connection through one-eighth and quarter bends to extend above the sink drain elevation, with horizontal portions sloped one-quarter inch per lineal foot. Cleanouts and wall cleanouts are provided on the piping runs, and sleeves are installed where pipes pass through the floor.
WCO CO 1/4 BEND 1/8 BEND 1-1/2" 1-1/2" SINK COUNTERTOP CABINET FLOOR 2" SEE NOTE #3 SEE NOTE #2 1-1/2" LONGTURN 1/4 BEND SLEEVE THRU FLOOR, TYP NOTES: 1. COORDINATE LOCATION OF VENT PIPING WITH CABINET CONSTRUCTION. 2. VENT PIPE EXTEND ABOVE SINK DRAIN ELEVATION. 3. SLOPE HORIZONTAL PORTION OF VENT 1/4" PER LINEAL FOOT TO WASTE CONNECTION. HORIZONTAL LENGTH TO BE LESS THAN 20 FEET.
