An overflow roof drain assembly penetrates a steel deck roof equipped with insulation and roofing. The drain body is supported by a receiver pan beneath the deck and secured with an underdeck clamp. A sixteen-gauge galvanized sheet metal plate is secured to the top of the strainer as a hood, extending two inches beyond the outside of the drain bowl with smoothed sharp edges to minimize rust staining at the overflow discharge.
ROOFING THIS POINT INTO DRAIN AT ROOFING CLAMPS PIECE EXTENSION ROOF DRAIN RECEIVER PAN UNDERDECK CLAMP STEEL DECK INSULATION OVERFLOW DRAIN DISCHARGE. TO MINIMIZE RUST STAINING AT ALL SHARP EDGES. HOOD IS INTENDED BEYOND OUTSIDE OF DRAIN BOWL. SMOOTH TOP OF STRAINER. EDGES TO EXTEND 2" 16 GAUGE GALV. S.M. PLATE, SECURED TO
