Discharge from the sprinkler main drain runs into a collector funnel with a reducer, maintaining a minimum air gap of two times the pipe diameter. The drain line routes through a P-trap to the sanitary sewer, accompanied by a floor drain and a vent pipe sized per plan. A drain sizes table specifies a four-inch gravity test drain at sixty gallons per minute and a six-inch pressure test drain at three hundred gallons per minute. Discharge must be adjusted to avoid drain line overflow, and a trap primer is required.
24" MAX PER UPC NOTES: 1. SEE FLOOR PLANS OR RISER DIAGRAM FOR PIPE SIZES. 2. TRAP PRIMER REQUIRED. 2x THE PIPE DIAMETER AIR GAP MINIMUM COLLECTOR FUNNEL REDUCER DISCHARGE FROM SPRINKLER MAIN DRAIN, DRAIN TO BE FULLY OPENED UNDER PRESSURE FOR MAXIMUM FLOW DURING TEST TO SANITARY SEWER DISCHARGE SHALL BE ADJUSTED TO AVOID DRAIN LINE OVERFLOW DRAIN SIZES GRAVITY TEST DRAIN 4"W 60 GPM PRESSURE TEST DRAIN 6"W 300 GPM VENT PIPE SEE PLAN FOR SIZE 3"V 4"V TO SANITARY SEWER FLOOR DRAIN
