A door scheduled per the drawings sits atop a threshold set over a concrete finish slab, with a maximum one-half inch clearance. A sealant over fiber joint filler is provided in the joint below the threshold level, maintaining finished floor alignment with adjacent panels.
CONCRETE FINISH SLAB DOOR AS SCHED, FIN TO MATCH ADJ PNL FF THRESHOLD 1/2" MAX 1/2" SEALANT O/ FIBER JOINT FILLER
