An all-thread rod suspends a copper band hanger supporting three-quarter to six-inch copper pipe. Insulation is provided to encapsulate the hanger when specified. The Tolco Figure 202 copper band hanger wraps around the pipe and insulation.
INSULATED AND NON-INSULATED COPPER PIPE 3/4" THRU 6" ALL THREAD ROD COPPER PIPE IF REQUIRED INSULATION TO ENCAPSULATE HANGER COPPER BAND HANGER "TOLCO" FIGURE 202
