A hollow structural section or cold-formed steel framing member is cantilevered at the edge below the Level 3 floor assembly at elevation 28 feet 1 inch. The steel framing supports the ceiling and edge conditions. The assembly integrates standard structural steel and framing components for interior ceiling transitions.
