A drain pan discharges into a three-quarter-inch diameter thinwall electrical metallic tubing conduit with flattened ends. The assembly includes associated piping, valves, and a mounting framework anchored against a wall with specified vertical spacings of four inches and nine inches.
9 8 11 7 6 2 1 5 10 4 14 7 15 4" 9" 3/4 " DIAMETER THINWALL (EMT) CONDUIT WITH ENDS FLATTENED. DRAIN PAN
