A gas supply line connects to gas-fired equipment through a ball valve, a sediment trap with a minimum 3-inch drop, and unions placed before and after a pressure-limiting gas pressure regulator. Capped tees are positioned at intervals along the run, maintaining a minimum distance of ten pipe diameters from fittings. The gas line maintains its full size to the air conditioning unit, and the regulator is installed in an upright position. A rubber grommet isolates the pipe penetration at the equipment connection.
CAPPED TEE UNION PRESSURE LIMITING DEVICE CAPPED TEE (WHERE APPLICABLE) GAS PRESSURE REGULATOR BALL VALVE 3" MIN. UNION SEDIMENT TRAP RUN GAS LINE FULL SIZE TO AIR CONDITIONING UNIT INSTALL REGULATOR IN UPRIGHT POSITION GAS FIRED EQUIPMENT RUBBER GROMMET 10 PIPE DIA. (MIN.)
