This assembly features a cleanout tee installed within a wall cavity, connected to a vertical pipe that may extend as a waste or vent line. The cleanout is accessed through the wall finish via a chrome wall cover secured with a screw. Below the finished floor, the assembly transitions to a one-eighth cast iron bend, with the remaining piping configuration matching standard floor cleanout requirements.
