A tuning fork stilling well is centered within a 4-inch sluiceway and positioned at a centerline elevation of 30.75. The assembly incorporates a quarter-inch 316 stainless steel plate measuring 5 inches wide by 23 inches long. A 45-degree PVC elbow points downward at the base of the well.
TYP P310 CL EL 30.75 45° PVC EL (DN) TUNING FORK STILLING WELL 1/4" 316 L ST PL 5" WIDE X 23" LONG 6 020-M-35-5001 4" NO. 3 CL SLUICEWAY
