The roof drain body is set into a steel deck and insulation assembly, supported by a receiver pan beneath the insulation. An extension piece connects the drain body through the deck assembly. An underdeck clamp secures the assembly from below with threaded fasteners. Roofing material clamps directly into the drain body at the top surface.
THIS POINT INTO DRAIN AT ROOFING ROOFING CLAMPS RECEIVER PAN STEEL DECK UNDERDECK CLAMP INSULATION EXTENSION PIECE ROOF DRAIN
