A control panel is mounted to horizontal Unistrut cross channels connected to vertical metal framing. The Unistrut channels are adjusted as needed to maintain the control panel centerline at four feet. The vertical framing members are secured at their base to drop-in epoxy set anchors with a minimum five-inch embedment into a reinforced concrete equipment pad.
