A half-inch cold water trap primer supply connects to a copper tee fitting on the main branch line within the wall. The trap primer valve is mounted vertically above the trap distribution unit, enclosed within a wall access panel whose size and location are confirmed in the field. Three-eighths-inch minimum annealed copper tubing extends from the distribution unit down to the floor drain trap primer connection. The trap primer valve must be mounted a minimum of twelve inches above the finished floor for every twenty feet of primer pipe.
"T" FITTING (COPPER) TRAP PRIMER VALVE ACCESS PANEL. CONFIRM SIZE & LOCATION IN FIELD TRAP DISTRIBUTION UNIT NOTE: TRAP PRIMER VALVE SHALL BE MOUNTED A MINIMUM OF 12" ABOVE FINISHED FLOOR FOR EVERY 20 FEET OF PRIMER PIPE 1/2" COLD WATER TRAP PRIMER SUPPLY COLD WATER HEADER OR MAIN BRANCH IN WALL 16" MINIMUM 3/8" MINIMUM ANNEALED COPPER TUBING (EACH FLOOR DRAIN). FINISHED FLOOR COPPER TUBE TO FLOOR DRAIN TRAP PRIMER CONNECTION (TYPICAL)
