A threaded rod suspends a formed steel clevis hanger that cradles a horizontal pipe. A protective saddle lines the bottom of the pipe interior, resting against the clevis base. The hanger is secured at the top with a bolt and nut assembly and is applicable for gravity support only.
DETAIL IS APPLICABLE FOR GRAVITY SUPPORT ONLY. 3 4 5
