Food service equipment connects to wall utilities via a flexible hose and shutoff valve assembly. The layout indicates offset dimensions from the finished face of the wall to the utility inlet on the equipment. Gas or water inlets connect directly to the flexible connector linked to the wall supply.
FACE OF WALL FINISHED FLOOR GAS OR WATER INLET FOOD SERVICE EQUIPMENT OFFSET FOOD SERVICE EQUIPMENT FACE OF WALL UTILITY INLET SECTION PLAN 2 3 4 1
