A water heater is anchored to a metal stud wall assembly constructed from six-inch eighteen-gauge studs spaced at sixteen inches on center with gypsum wallboard. The water heater is supported against the wall using a Unistrut P1000 channel secured to the studs with half-inch through-bolts and washers. Three-quarter-inch by twenty-two-gauge perforated metal straps wrap around the water heater and connect to the Unistrut assembly. Gypsum wallboard spacers maintain a minimum one-inch clearance from the wall surface. Number fourteen sheet metal screws fasten the components together, and associated electrical and plumbing accessories include a one-day time clock, aquastat, and condensate trap.
GYPSUM WALLBOARD SPACER 1"MINIMUM E E 1 120V. 1∅ STRAP ON A AQUASTAT MAKE AT 100° AND BREAKED AT 108° 1 DAY TIME CLOCK CPH-2 120V. 1∅ B - WATER HEATER ANCHORAGE ON METAL STUD PROVIDE WITH DRAIN CONNECTION, VALVE & PLUG. 2 NOTE: 1 DRAIN PIPE SAME SIZE AS RELIEF VALVE 3 PUMPS WITH 365 DAYS PROGRAMMABLE TIMER. PROVIDE BY PLUMBING CONTRACTOR, SEE SCHDULE P0.12 FOR RECIRCULATING (TO MAINTAIN THE HOT WATER TEMPERATURE IN THE PIPING, SET THE LENGTH OF THE TIMING CYCLE AS REQUIRED.) CONDENSATE TRAP WITH CD DRAIN PER MANUFACTURER'S INSTALLATION MANUAL 3/4"x22 GA GAUGE PERFORATED METAL STRAP WATER HEATER 6"x18 GA. STUD 16" ON CENTER. METAL STUD WALL(TYP.) #14 SHEET METAL SCREWS UNISTRUT P1000 WITH WASHER 1/2" THRU BOLT
