A pipe, duct, or conduit passes through an existing concrete wall utilizing a wall sleeve sized to match the specified mechanical seal. The annular space on the dry side is filled with non-shrink grout. A modular mechanical seal or approved equal is installed on the wet side per the manufacturer's recommendations.
WALL SLEEVE TO MATCH LINKSEAL SPECIFICATION (E) CONCRETE WALL PIPE, DUCT OR CONDUIT DRY SIDE WET SIDE FILL ANNULAR SPACE W/NON-SHRINK GROUT INSTALL LINKSEAL OR EQUAL PER MANUFACTURER'S RECOMMENDATIONS PENETRATION
