An electric water heater is mounted on a two-inch insulation pad and a drain pan, with the tank drain piped to a floor drain. The unit features a three-quarter-inch relief valve and a vacuum breaker on the domestic water piping. An expansion tank is connected to the system, and a hot water circulation pump line includes a one-half-inch ball valve with a balancing stop. Pipe sizes and system diagrams are to be verified per plans. The water heater is seismically braced to the adjacent wall per code requirements.
1/2" BALL VALVE WITH BALANCING STOP SEE PLANS AND/OR DIAGRAMS FOR SIZES, TYP SEE PLANS AND/OR DIAGRAMS FOR SIZES, TYP NS EXPANSION TANK 3/4" RELIEF VALVE WATER HEATER SEISMICALLY BRACE TO WALL PER CODE (TYP.) PIPE TANK DRAIN TO DRAIN DRAIN PAN 2" INSULATION PAD 3/4" DRAIN DRAIN 3/4" RELIEF HWCP 1 XT 1 VACUUM BREAKER
