A cast iron cleanout tee with a countersunk plug is connected to the building drain pipe behind a finished wall. The cleanout assembly is secured with anchor lugs and finished with a face-of-wall stainless steel cover plate set flush with the wall surface.
PIPE SIZE FINISHED WALL CAST IRON CLEANOUT TEE WITH COUNTERSUNK PLUG ANCHOR LUGS FACE-OF-WALL STAINLESS STEEL COVER BUILDING DRAIN FLR. FIN.
