A hot-dip galvanized steel pour frame is embedded directly into the concrete sump pit edge. The assembly supports a nineteen-W-four steel bar grating with one-by-one-eighth-inch bars. Three-eighths-inch by four-inch long J-anchor bolts secure the frame at a maximum of eight inches on center with a minimum of three inches per side for the square sump pump discharge.
DETAIL A 14 24"X24" HOT DIP GALVANIZED "E-Z" POUR FRAME EMBEDDED IN CONCRETE 19-W-4 STEEL BAR GRATING, 1X 1 8 " BAR BY GRATING PACIFIC OR EQUAL FRAME COMPLETED WITH 3 8 "X4" LONG J-ANCHIR BOLT MAX 8"O.C. MIN. 3" PER SIDE FOR SQUARE SUMP PUMP DISCHARGE
