A piping schematic and valve arrangement for a heating or cooling coil incorporates a 3-way modulating control valve alongside a calibrated balancing valve and a strainer for flow regulation and debris protection. Isolation valves and pressure-temperature test plugs are positioned to facilitate maintenance and system diagnostics. A three-quarter-inch ball valve with a hose thread drain connection and an air vent at the high point are included to manage drainage and air purging.
A CALIBRATED UNION, TYP. COIL STRAINER 3-WAY MODULATING CONTROL VALVE 3/4" BALL VALVE WITH HOSE THREAD DRAIN CONNECTION ARRANGE PIPING TO MAINTAIN REQUIRED SEVICE CLEARANCE ISOLATION VALVE BALANCING VALVE PLUG, TYP. P & T TEST NO NC AIR VENT AT HIGH POINT
