Rectangular or round ductwork passes through a drywall partition framed with metal studs and gypsum board. A minimum twenty-two gauge sheet metal sleeve lines the opening, surrounded by fiberglass insulation and a backer rod. A one-quarter-inch gap around the perimeter is filled with acoustical sealant on both sides. Minimum twenty-two gauge sheet metal angle rings are secured to the sleeve to finish each side of the penetration.
FIBERGLASS INSULATION SHEET METAL ANGLE RING (MIN. 22 GA.) SECURE TO SLEEVE. DUCT INSULATION (WHERE REQD) METAL STUD SHEET METAL SLEEVE (MIN. 22 GA.) DRYWALL PARTITION RECTANGULAR OR ROUND DUCTWORK 1/4" GAP AROUND PERIMETER FILLED WITH ACOUSTICAL SEALANT (TYP BOTH SIDES) DUCT LINER (WHERE REQD) BACKER ROD
