Standard sheet-metal ductwork transitions illustrate maximum taper angles for airflow management in plan or side view. The details outline a fifteen-degree maximum typical angle for converging and diverging duct runs, alongside a thirty-degree maximum typical angle for inline equipment transitions. Unless indicated otherwise on plans, these maximum transition angles apply to all standard duct layouts.
EQUIPMENT TYPICAL DUCTWORK TRANSITION PLAN OR SIDE VIEW TYPICAL DUCTWORK TRANSITION WITH EQUIPMENT MOUNTED IN DUCT PLAN OR SIDE VIEW AIRFLOW NOTES: 1. UNLESS OTHERWISE INDICATED ON PLANS, MAXIMUM ANGLES SHOWN SHALL APPLY. AIRFLOW AIRFLOW 15° MAX. (TYP) 30° MAX. (TYP) 15° MAX. (TYP)
