An upblast roof exhaust fan with a direct drive motor and control dial for balancing mounts atop a pre-fabricated factory curb secured to minimum four-inch nominal thick wood timber framing. Roofing material transitions up the curb with a cant strip and flashing. A backdraft damper installs within the roof opening below the fan unit.
PROVIDE PRE. FAB. FACTORY CURB CONTRACTOR TO MIN. 3" THREAD ENGAGEMENT 3/8" LAG BOLT ROOF CAP CANT STRIP ROOFING MATERIAL WOOD TIMBER MIN. 4" NOM. THICK BACKDRAFT DAMPER ROOF EXHAUST FAN DIRECT DRIVE FOR BALANCING CONTROL DIAL 9 UPBLAST ROOF EXHAUST FAN 3
