An upblast grease exhaust fan mounts on a twenty inch tall vented and hinged curb with grease removal ports, positioned over a roof duct penetrating a metal insulated roof with TPO membrane. A one-half by two-inch neoprene pad runs all around beneath the fan base. A backdraft damper installs inside the duct with a three-inch minimum clearance. The exhaust fan sits a minimum of forty inches above the roof surface, requiring coordination with structural and architectural trades for bracing.
DUCT PAD ALL AROUND 1/2" X 2" NEOPRENE 3" MIN BACKDRAFT DAMPER 20" TALL CURB. VENTED, HINGED CURB WITH GREASE REMOVAL PORTS FOR GREASE EXHAUST FAN COORDINATE WITH STRUCTURAL AND ARCHITECTURAL FOR BRACING. EXHAUST FAN MIN 40" ABOVE ROOF METAL INSULATED ROOF WITH TPO
