Double B-Line Unistrut channels frame the vertical support with lateral cross braces positioned at a forty-five degree angle. Seismic connections anchor the assembly to the base structure with typical sizing callouts indicated on the drawing. The diagonal bracing ties back to the upper equipment housing at Detail C while the base mounts via bolted connections.
FRONT VIEW 45° A-A SIDE VIEW DETAIL C SEISMIC (TYP.) DOUBLE B-LINE UNISTRUT LATERAL CROSS BRACE (TYP. 2) SIZE? DETAIL A ? ?
Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
