The rooftop mounted equipment rests upon a four-inch by ten-inch wood nailer leveling curb. The unit base is secured with bolts passing through the base, or alternatively bolted to a spring isolator which is lagged to the curb. A metal cap flashing covers the top of the curb, protected by a Flintlastic modified bitumen cap sheet. The basis of design is a Greenheck unit.
NOTES: 1. BASIS OF DESIGN: GREENHECK 14"MAX P8"MIN. 4" ROOF MOUNTED EQUIPMENT BOLTS THROUGH UNIT BASE. REFER TO EQUIPMENT INSTALLATION MANUAL FOR DETAILS. IF SPRING ISOLATOR IS REQ'D, BOLT UNIT TO ISOLATOR AND LAG ISOLATOR TO CURB METAL CAP FLASHING BY MC 4"x10" WOOD NAILER LEVELING CURB BY GC FLINTLASTIC MODIFIED BITUMEN CAP SHEET SCALE: NTS M-L01 6 ROOFTOP EXHAUST FAN DETAIL
