A roof-mounted condenser unit connects via hot gas and liquid refrigerant lines to a wall-mounted split system heat pump. Piping is sized and installed per the manufacturer's recommendations and direction. A check valve and a coordinate-planned condensate drain tie into the wall-mounted unit. A hard-wired thermostat controls the heat pump system.
CONDENSER ON ROOF SIZE PIPING PER MANUFACTURER'S RECOMMENDATION PIPE PER MANUFACTURER'S DIRECTION HOT GAS LINE UP LIQUID LINE UP SPLIT SYSTEM/HEAT PUMP MOUNTED ON WALL CHECK VALVE CONDENSATE DRAIN (COORDINATE WITH PLAN) HARD-WIRED T'STAT
