A surface-mounted ceiling diffuser connects to a rigid duct secured by sheet metal screws, which transitions to a flexible duct limited to a maximum length of three feet and fastened with a cinch band. The ceiling system is coordinated per architectural plans, and the diffuser and ceiling inlets and outlets require independent support to prevent transferring loads to the grid.
FLEXIBLE DUCT SEE SPECIFICATION (3'-0" MAXIMUM LENGTH) CEILING SYSTEM SEE ARCHITECTURAL PLANS CEILING DIFFUSER SECURE FLEXIBLE DUCT WITH CINCH BAND RIGID DUCT SECURE DUCT TO DIFFUSER WITH SHEET METAL SCREWS NOTE: CEILING INLETS AND OUTLETS SHALL BE INDEPENDENTLY SUPPORTED. CEILING DIFFUSER SHALL BE INDEPENDANTLY SUPPORTED
