The roof drain assembly integrates into a steel deck roof system with continuous insulation. The roof membrane extends into the drain body and secures with roofing clamps. A receiver pan supports the drain assembly above the steel deck, while an underdeck clamp secures the assembly from below. An extension piece accommodates the thickness of the insulation layer.
THIS POINT INTO DRAIN AT ROOFING ROOFING CLAMPS RECEIVER PAN STEEL DECK UNDERDECK CLAMP INSULATION EXTENSION PIECE ROOF DRAIN THIS POINT INTO DRAIN AT ROOFING ROOFING CLAMPS RECEIVER PAN STEEL DECK UNDERDECK CLAMP INSULATION EXTENSION PIECE ROOF DRAIN
