Rectangular supply ducts and round supply ducts connect to double deflection sidewall diffusers equipped with integrated opposed blade dampers for airflow control. Sizing for both the ductwork and the diffusers is referenced per drawings M-100 through M-109. The round duct configuration incorporates a forty-five degree angular takeoff leading into the damper and diffuser assembly.
RECTANGULAR SUPPLY DUCT, SEE M-100 THRU M-109 FOR SIZE. OPPOSED BLADE DAMPER DOUBLE DEFLECTION SIDE WALL DIFFUSER SEE M-100 THRU M-109 FOR SIZE ROUND SUPPLY DUCT, SEE M-100 THRU M-109 FOR SIZE. OPPOSED BLADE DAMPER DOUBLE DEFLECTION SIDE WALL DIFFUSER SEE M-100 THRU M-109 FOR SIZE 45.00°
