A mechanical pipe penetration passes through a metal roofing assembly. A pre-molded ethylene propylene diene monomer (EPDM) or rubber boot surrounds the pipe, featuring an intact manufacturer's rib or lip at the top secured by a stainless steel clamping ring. Sealant is applied at the top of the boot around the pipe and along the lap joints with approximately a one-half inch overlap. Base flashing is provided by the general contractor and sealed with in-seam sealant. Installation instructions require modification to match the specific roofing type and ensure a watertight seal.
REFER TO ARCHITECTURAL DRAWINGS FOR ROOF CONSTRUCTION. REFER TO PLANS FOR SIZE AND LOCATION BASE FLASHING BY GENERAL CONTRACTOR PRE-MOLDED EPDM OR RUBBER BOOT, INSTALLED PER MANUFACTURER'S INSTRUCTIONS STAINLESS STEEL CLAMPING RING MAINTAIN INTACT MANUFACTURER'S RIB OR LIP AT TOP OF BOOT IN-SEAM SEALANT NOTE: MODIFY INSTALLATION TO MATCH ROOFING TYPE AND INSTALL PER MANUFACTURER'S INSTRUCTIONS TO BE WATER-TIGHT. LAP SEALANT APPROX. 1/2" SEALANT METAL ROOFING
