A main low pressure duct connects to branch metal or flexible ductwork through a takeoff equipped with a volume damper. Duct sealant is applied all around the connection, secured with a clamp required for flexible ductwork, and wrapped in duct wrap insulation. Separate diagrams specify maximum transition slopes of one to four for low velocity supply and return ductwork under two thousand feet per minute, and one to seven for high velocity systems over two thousand feet per minute.
1 7 RETURN AIR AIR FLOW SUPPLY AIR AIR FLOW 1 7 1 4 4 MAX. SLOPE OF TRANSITION (UNLESS OTHER- WISE SHOWN) 1 LOW VELOCITY SUPPLY AND RETURN AIR DUCTWORK (DUCT VELOCITY LESS THAN 2000 FPM) HIGH VELOCITY SUPPLY AND RETURN AIR DUCTWORK (DUCT VELOCITY MORE THAN 2000 FPM) MAX. SLOPE OF TRANSITION (UNLESS OTHER- WISE SHOWN) RETURN AIR AIR FLOW SUPPLY AIR AIR FLOW DUCT WRAP INSULATION VOLUME DAMPER MAIN L.P. DUCT DUCT SEALANT ALL AROUND CLAMP (REQUIRED FOR FLEXIBLE DUCTWORK) INSULATION METAL OR FLEXIBLE DUCTWORK AIR FLOW
