Single pipe support assembly utilizing all-threaded rod attached to the overhead structure with accessories, secured by typical lock and locknuts. A pipe hanger or Superstrut C-710 or C-711 or equal supports the pipe encased in a twenty-six gauge sheet metal saddle. An accompanying schedule outlines minimum rod sizes and maximum support spans for pipe sizes ranging from up to one inch to twelve inches in diameter.
PIPE SIZE UP TO 1" 2 TO 2-1/2" C-711 8 10 12 3" 3-1/2" 4 5 6 (IN) 1-1/2" SUPERSTRUT C-710 19 7/8" 7/8" 7/8" 22 23 MIN. ROD SIZE (IN) 3/8" 3/8" 3/8" 1/2" 1/2" 5/8" 5/8" 3/4" 12 13 14 16 17 MAX SUPPORT SPAN (FT) 10 7 9 26 GA.SHT. METAL SADDLE ALL THREADED ROD (SEE SCHEDULE) PIPE HANGER SUPERSTRUT LOCK & LOCKNUT (TYP) ATTACH TO STRUCTURE WITH ACCESSORIES AS REQUIRED OR EQUAL OR EQUAL DUCTS 35" DIA. & SMALLER THIS HANGER IS FOR SINGLE PIPE SUPPORT 5
